PART CPVC80F853-030C

SUPPLIER Lasco®

SUPPLIER PART # 9853-030

Calculating price...

QUANTITY

Lasco® Blind Flange, 3 in Nominal, 8 Bolt Holes, 5/8 in, SCH 80/XH, CPVC, Domestic

ANSI B16.5|NSF 61

Bolt Hole Size 5/8 in

Domestic/Import Domestic

Material CPVC

Nominal Size 3 in

Number of Bolt Holes 8

Schedule Rating SCH 80/XH

Brand Lasco®

Country of Origin US

Warranty Limited

Listings - NSF 61 (National Sanitation Foundation) for potable water services

Do not use lasco fittings for compressed air or gases

Do not test PVC piping systems with compressed air or gases

Do not use fittings with liquids not recommended by lasco

Fitting modification voids the warranty

Recommended gaskets, full face 1/8 in thick elastomeric, 50 to 70 shore A hardness

Bolt threads should be well lubricated

Nut and bolt threads should be free-running during assembly

Always use full size flat washers with bolts and nuts

Use primer and heavy bodied PVC cement

5/8-11 UNC x 3-5/8 in L bolt

Code - 03/B3
