Home Valves & Actuators Check Valves & Backflow Preventers Ball Check Valves CPVC TU BALL CHK 4 EPDM O-RINGS SKT END

CPVC TU BALL CHK 4 EPDM O-RINGS SKT END

PART HAY TC2400SE
SUPPLIER HAYWARD®
SUPPLIER PART # TC2400SE
Calculating price...
QUANTITY

About this item

HAYWARD® Ball Check Valve, True Union, Series: TC Series, 4 in Nominal, Socket, 150 psi, 70 deg F, Full Port, 12.94 in Inlet to Outlet Length, CPVC Body, EPDM Softgoods, 8.56 in H

TC Series true union ball check valves are offered in PVC, CPVC, and PP. O-rings and seats are FPM or EPDM. 1/4 in. and 3/8 in. sizes are PVC only and are trim check design. They have socket or threaded end connections. Others up to 2 in. sizes have socket and threaded end connections. All valves are assembled with silicone free lubricant.

Class 23447 per ASTM D1784|NSF/ANSI 61
Body Material CPVC
Dimensions 8.56 in H
End Style Socket
Inlet to Outlet Length 12.94 in
Nominal Size 4 in
Port Type Full
Pressure Rating 150 psi
Series TC Series
Softgoods Material EPDM
Temperature Rating 70 deg F
Type True Union
Brand HAYWARD®
Warranty 2 Years
  • For horizontal or vertical installation
  • Square cut seat for positive sealing
  • Seats with minimum back pressure
  • Sure block design
  • EPDM O-ring
